TUOZHAN TZ35UVA+UVC02-002
PaylaşFavorilere Ekle
Üretici:TUOZHAN
MFR. Part #:TZ35UVA+UVC02-002
LCSC Part #:C688875
Kılıf:SMD3535-4P
Müşteri #:
Özellikler:5V SMD3535-4P LED Emitters - Infrared, UV, Visible RoHS
Datasheet:
TUOZHAN TZ35UVA+UVC02-002
Stok: 6612-4 Hafta İçinde Teslim
MiktarBirim Fiyat
1
60,22714 ₺
KDV Dahil Toplam Tutar:
60,22714 ₺
| Miktar | İndirim | Birim Fiyat |
| 1 - 9 | %0 | 60,22714 TL |
| 10 - 29 | %19 | 48,78398 TL |
| 30 - 99 | %28 | 43,36354 TL |
| 100 - 499 | %38 | 37,34083 TL |
| 500 - 999 | %49 | 30,71584 TL |
| 1000 - 10000000 | %52 | 28,90903 TL |
Koleksiyon +Fiyat Alarmı
Ürün Açıklaması
5V SMD3535-4P LED Emitters - Infrared, UV, Visible RoHS
Ürün Özellikleri
| Özellik Tipi | Açıklama | |
|---|---|---|
| MPN | TZ35UVA+UVC02-002 | |
| Package | SMD3535-4P | |
| Manufacturer | TUOZHAN | |
| Peak Wavelength | 390nm~400nm@UVA;270nm~285nm@UVC | |
| Current - DC Forward(If) | 200mA@UVA;30mA@UVC | |
| Reverse Leakage Current (Ir) | 3uA;1uA | |
| Voltage - Forward(Vf) | 3.2V@UVA;6.5V@UVC | |
| Pd - Power Dissipation | 500mW@UVA;240mW@UVC | |
| Viewing Angle | 120° | |
| Voltage - DC Reverse(Vr) | 5V | |
| Operating Temperature | -40℃~+80℃ | |
| Radiant Flux | 20mW;2.5mW |
